Maximum Operating Pressure
Maximum Cylinder Capacity Advance
- 11.1 - 565.7 tons (101 - 5108 kN)
Maximum Cylinder Capacity Retract
Stroke
- 2.25 - 48 inches (57 - 1219 mm)
Collapsed Height A
- 7.19 - 64.75 inches (183 - 1644 mm)
Extended Height B
- 9.44 - 112.75 inches (240 - 2863 mm)
Return Type
- Double Acting, Hydraulic Return
Cylinder Effective Area Advance
- 2.23 - 113.15 in² (14.5 - 729.7 cm²)
Cylinder Effective Area Retract
- 0.8 - 63 in² (4.8 - 405.4 cm²)
Oil Capacity Advance
- 22.33 - 5431 in³ (368 - 88,951 cm³)
Oil Capacity Retract
- 8 - 3024 in³ (122 - 49,418 cm³)
Weight
- 28 - 2700 lbs (12 - 1224 kg)
