Maximum Operating Pressure
Cylinder Compatibility
- Double-Acting
- Single-Acting
Reservoir Capacity
- PA1021 & 1041: 162 in³ (2600 cm³)
- PA1022 & PA1042: 462 in³ (7600 cm³)
Usable Oil Capacity
- PA1022 & 1042: 7.6 litres (2 gallon)
- PA1021 & 1041: 2.6 litres (0.7 gallon)
Maximum Flow at Rated Pressure
- 9 in³/min (0.15 litre/min)
Output Flow Rate 1st Stage
- 650 in³/min (10.65 litres/min)
Output Flow Rate 2nd Stage
- 9 in³/min (0.15 litres/min)
Valve Function
- Advance/Hold/Retract
- Advance/Retract
Valve Type
- 3-Way, 2-Position
- 4-Way, 3-Position, Tandem Center
Air Pressure Range
- 60-120 psi (4.1 - 8.3 bar)
Weight
- 50 lbs (22.7 kg)
- 60 lbs (27.2 kg)
