Maximum Operating Pressure
Maximum Cylinder Capacity Advance
- 4.9 - 103.1 tons (45 - 498 kN)
Stroke
- 0.63 - 14.25 inches (16 - 362 mm)
Collapsed Height A
- 1.63 - 19.38 inches (41 - 492 mm)
Extended Height B
- 2.25 - 33 inches (57 - 838 mm)
Return Type
- Single-Acting, Spring Return
Cylinder Effective Area Advance
- 0.99 - 20.63 in² (6.4 - 133.1 cm²)
Oil Capacity Advance
- 0.62 - 211.45 in³ (10 - 3466 cm³)
Weight
- 2.2 - 160 lbs (1.0 - 72.6 kg)
