A Series - Arbor & C-Clamp Hydraulic Presses

Brand: Enerpac
Request Information
Favorite

005.png 0011.png 002.png 003.png
Specifications
  • A330 & A310
    • Foot mounting holes for horizontal or vertical positioning
    • Machined working surface for easier fixturing
    • Slotted back to simplify loading and unloading of longer parts
  • A220 & A205
    • 20 & 5 ton capacity respectively
    • Operational in all positions
  • A210
    • 10 capacity
    • Operational in all positions
    • Push Pin A183 For applications requiring precision pressing, such as shaft removal and insertion. This attachment fits 10 ton cylinders and requires the use of a threaded adaptor saddle A13
    • Smooth Saddle A185 for pressing applications of delicate parts, such as aluminum castings, this saddle decreases surface marks during the pressing application. Requires 10-ton cylinder and threaded adaptor saddle A13

View Details

Specifications

Brand

Maximum Operating Pressure

  • 10,000 psi (700 bar)

Press Capacity

  • 5 tons (45 kN)
  • 10 tons (89 kN)
  • 20 tons (178 kN)
  • 30 tons (267 kN)

Maximum Vertical Daylight

  • 6.5 in (165 mm)
  • 9 in (228 mm)
  • 9.06 in (227 mm)
  • 11.88 in (305 mm)
  • 10 in (260 mm)

Maximum Bed Width

  • 2 inch (51 mm)
  • 3.25 in (57 mm)
  • 5.31 in (135 mm)
  • 3.75 in (70 mm)
  • 7 in (178 mm)

Compatible Cylinders

  • RC50,RC51,RC53,RC55,RC57,RC59,RC101,RC102,RC104,RC106,RC108,RC1010,RC1012,RC1014,RC251,RC252,RC254,RC256,RC258,RC2510,RC2512,RC2514,R308

Cylinder Type

  • Single-Acting

Weight

  • 14 lbs (7 kg)
  • 37 lbs (17 kg)
  • 62 lbs (28 kg)
  • 83 lbs (38 kg)
  • 220 lbs (100 kg)
