ACPN Series 2-Way General Purpose Solenoid Valve
Brand: Alcon Solenoid Valves - by RotorkSpecifications
- Heavy Duty Valve Design
- Piston Operation
- Wide Temperature Range Capabilities
- Choice of Valve Body Material and Seals
Specifications
Body Material
- Bronze
- Brass
- Stainless Steel
Environmental Protection
- Din Connector: NEMA 4
- Metal Enclosure: NEMA 2
Seal Material
- EPDM at -50° to 120° C (-58° to 248° F)
- Nitrile (Buna-N) at -10° to 80° C (14° to 176° F)
- PTFE at -196° to 180° C (-321° to 356° F)
- Viton at -20° to 150° C (-4° to 302° F)
Ambient Temperature
- -10° to 50° C (14° to 122° F)
Pipe Size
- 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
