TMR Coriolis Mass Flowmeter
Brand: KOBOLD Instruments, IncThe TMR Series Mass Flow Meter utilizes the Coriolis principle of operation to measure mass flow. Density and temperature are simultaneously monitored and volumetric flow is additionally calculated with these parameters.
The TMR Series is available with a direct mounted transmitter or in a remote mounted configuration.
Displaying prices & availability for Ohio, United States in CAD. Change location.
Models matching criteria: 4
- Measuring Range - 2,000 to 20,000 kg/hour (lbs/min)
100+ In Stock
$2,500.00 CAD
Does not ship to OH, United States
- Measuring Range - 25,000 to 120,000 kg/hour (lbs/min)
25+ In Stock
$1,174.00 CAD
Does not ship to OH, United States
- Measuring Range - 120 to 1,200 kg/hour (lbs/min)
25+ In Stock
$996.00 CAD
Does not ship to OH, United States
- Measuring Range - 6,000 to 60,000 kg/hour (lbs/min)
21 In Stock
$1,453.00 CAD
Does not ship to OH, United States
Specifications
Accuracy
- ± 0.1 % of Reading, ± Zero Point Stability up to TMR040
- ± 0.15 % of Reading, ± Zero Point Stability from TMR080
Ambient Temperature Range
- -20° to 80° C (-4° to 176° F) - Special Version
- -40° to 100° C (-40° to 212° F) - Remote Mounted Transmitter
Applications
- Chemical & Petrochemical
- Oil Industries
Approvals & Certifications
- ASME B16.5
- ASME Class 150, 300, 600 - Standard
- DMT 01-ATEX-E 149 X
- EN 1092
- PED 97/23/EC
Communication
- HART
- Modbus RTU (RS-485)
- PROFIBUS PA
Consumption
- 200 mA at 24 Vdc
- 3 W
Electrical Connectors
- Junction Box
- Plug Connection
Enclosure / Body Material
- 304 Stainless Steel
- 304L Stainless Steel up to TMR040
Environmental Protection
- Intrinsically Safe - Sensor Circuits
- IP65
- IP68 (EN 60529)
- NEMA 4X
- NEMA 6
Flange Material
- 316L Stainless Steel
- 316Ti Stainless Steel
Flange Size - 1-1/2” (DN 40)
- 1-1/2” (DN 40) - 150# ASME
- 1-1/2” (DN 40) - 300# ASME
- 1-1/2” (DN 40) - 600# ASME
Flange Size - 1” (DN 25)
- 1” (DN 25) - 150# ASME
- 1” (DN 25) - 300# ASME
- 1” (DN 25) - 600# ASME
- 1” (DN 25) - PN 40
Flange Size - 2-1/2” (DN 65)
- 2-1/2” (DN 65) - PN 40
Flange Size - 2” (DN 50)
- 2” (DN 50) - 150# ASME
- 2” (DN 50) - 300# ASME
- 2” (DN 50) - 600# ASME
- 2” (DN 50) - PN 40
Flange Size - 3/4” (DN 20)
- 3/4” (DN 20) - 150# ASME
- 3/4” (DN 20) - 300# ASME
- 3/4” (DN 20) - 600# ASME
- 3/4” (DN 20) - PN 40
Flange Size - 4” (DN 100)
- 4” (DN 100) - 150# ASME
- 4” (DN 100) - 300# ASME
- 4” (DN 100) - 600# ASME
- 4” (DN 100) - PN 40
Frequency
- 1 kHz
Input
- 200 mA
- 30 V
- Active
- Counter Reset - Input Binary
Materials of Construction
- 316L Stainless Steel - Flow Tubes, Splitter
- 316Ti Stainless Steel - Flow Tubes, Splitter
Mounting
- Integrated
- Remote Mounting
Nominal Pressure
- psi: 580.2 (bar: 40, kPa: 4,000)
Output
- 30 V
- 4-20 mA
- Galvanically Isolated
- Optocoupler
- Passive
Power Requirement
- 19-36 Vdc
- 24 Vac ± 20 %
- 90-265 Vac
Process Temperature
- -40° to 260° C (-40° to 500° F)
RFI/EMI Effect
- EMC-Directive 89/336/EEC
- EN 61000-6-3: 2001 (Emissions Residential Environments), EN 61000-6-2: 1999 (Immunity for Industrial Environments)
