Alcon 2-Way General Purpose Solenoid Valve, HP Series
Images are representations only.

HP Series 2-Way General Purpose Solenoid Valve

Brand: Alcon Solenoid Valves - by Rotork
Request Information
Favorite

Specifications
  • Ideal for High Pressure Applications
  • Compact Valve Design
  • Piston Operated
  • Choice of Valve Body Material and Seals

View Details

Specifications

Brand

Body Material

  • Brass
  • Stainless Steel

Environmental Protection

  • Din Connector: NEMA 4
  • Metal Enclosure: NEMA 2

Seal Material

  • VITON at -20° to 150° C (-4° to +302° F)
  • EPDM at -20° to 120° C (-4° to 248° F)
  • PTFE at -20° to 180° C (-4° to 356° F)
  • Stainless Steel at -20° to 180° C (-4° to 356° F)

Electrical Connection

  • 9 mm Din Connector (DIN 43650)
  • 1/2” NPT Conduit Hub with 18” Leads

Coil Insulation

  • Class H Suitable for Continuous Duty

Ambient Temperature

  • (-10° to 50° C) 14° to +122° F

Pipe Size

  • 1/4", 3/8", 1/2"
