The PM ET-487 HMI series includes Panel PCs for panel mounting in hazardous zones 1, 2, 21, 22 and Division 2.
Their brilliant 24" WU widescreen displays with a resolution of 1920 x 1200 pixels (format 16:10) are available with or without touch screen.
Accessories such as country-specific keyboards, pointer instruments and RFID and barcode scanners make work easier and extend functionality.
The state-of-the-art quad core processors can be complemented with various memory sizes and SSDs.
The following four types of data transmission technology are available: dual or single Ethernet as 10/100Base-TX via CAT-7 up to 100 m, single Ethernet as 1000Base-SX via multimode fibre optiic up to 550 m and single Ethernet as 1000Base-LX via single mode fibre optic up to 10 km.
Features- Panel PC for panel mounting, quad core ATOM E3845, 24"WU display, 1920 x 1200
- Zone 1, 2, 21, 22, can be installed in hazardous areas without additional enclosure
- Optional resistive glass or foil touch screen
- Panel PC for panel mounting, quad core ATOM E3845, 24"WU display, 1920 x 1200
- Zone 1, 2, 21, 22, can be installed in hazardous areas without additional enclosure
- Optional resistive glass or foil touch screen
